Mechanical Values
Tensile Strength: 12,000Pounds (53kN)
Electrical Values
Low-frequency Dry Flashover Voltage: 30kV
Low-frequency Wet Flashover Voltage: 15kV
| parameter | ANSI 54-2 | IEC 60383 | GB/T 1001.1 |
| Rated load | 54.4kN | 70kN（Class 70） | 70kN（(Level 70) |
| Creepage distance | 203mm（8 inches） | 320mm（Class III Filth) | 300mm（(Level III.) |
| Dry lightning pressure | 110kV | 170kV(Standard type) | 165kV |
Typical Applications:
Tensile section of the transmission line
Cable termination tower tension support
Railway electrification catenary hard crossing
The substation bus is fixed
