Mechanical Values
Combined M&E Strength: 15,000Pounds(67kN)
Impact Strength: 55Inch-Pounds(6.2Nm)
Routine Proof Test Load: 7,500Pounds(33.5kN)
Time Load Test Value: 10,000Pounds(44.5kN)
Maximum Working Load: 7,500Pounds(33.5kN)
Electrical Values
Low Frequency Dry Flashover Voltage: 80kV
Low Frequency Wet Flashover Voltage: 50kV
Critical Impulse Flashover Votage Positive: 125kV
Critical Impulse Flashover Votage Negative: 130kV
Low Frequency Puncture Voltage: 110kV
Radio Influence Voltage Data
Test Voltage RMS to Ground: 10kV
Maximum RIV at 1000 kHz: 50μV
